Self-Clinching Locating Pins
Self-Clinching Locating Pins
RivetFast Self-Clinching Locating Pins are designed to provide precise positioning and alignment of components in thin sheet metal assemblies.
They ensure repeatable assembly accuracy, reduce errors, and support reliable mechanical function in industrial and electronic applications.
What are Self-Clinching Locating Pins?
Self-clinching locating pins are press-fit fasteners that embed permanently into sheet metal, creating a fixed guide for mating components.
They are ideal for aligning panels, housings, or internal components where precision and repeatability are required.
Once installed, they resist rotation and push-out, forming a stable alignment solution.
Key Advantages of Self-Clinching Locating Pins
Accurate and repeatable component positioning
Permanent embedding in thin sheet metal
High push-out and torque resistance
Flush installation for clean surfaces
Supports precision assemblies in electronics and industrial equipment
Available Materials, Head Types & Surface Finishes
Materials
Carbon Steel、Stainless Steel
Customized sizes and colors are available according to customer drawings.
Specifications & Size Options for Self-Clinching Locating Pins
Diameter sizes: M2–M6 (custom sizes available)
Lengths: Standard guide lengths; custom lengths on request
Surface finish: Optional based on application needs
Installation Guidelines for Self-Clinching Locating Pins
Use press-fit installation with parallel pressing surfaces
Ensure correct hole diameter and compatible sheet thickness
Apply controlled force to achieve full embedding
Verify flush and secure seating after installation
Locating Pins vs Spring-Loaded Screws
| Feature | Locating Pins | Spring-Loaded Screws |
|---|---|---|
| Function | Alignment & positioning | Controlled movement / preload |
| Installation | Press-fit | Press-fit |
| Surface | Flush | Flush |
| Typical use | Precision assembly | Flexible or vibration-prone |
Typical Applications for Self-Clinching Locating Pins
- Panel alignment in electronic housings
- Industrial equipment assembly requiring precise component positioning
- Sheet metal enclosures and frames
- Control panels and cabinets
Customization, Quality Control & Supply Capability
Customization: Threaded or unthreaded pins, custom diameters, lengths, materials, and finishes
Quality Control: ISO-certified production and testing for push-out strength, dimensional accuracy, and repeatability
Supply Capability: Stable production and fast lead times for prototypes or high-volume orders
Why Choose RivetFast for Your Self-Clinching Fasteners？
ISO 9001 Certified Manufacturing
All RivetFast self-clinching fasteners are produced under an ISO 9001 certified quality management system, ensuring consistent quality and process control.
Designed for Secure Sheet Metal Assembly
Engineered to permanently install into thin sheet materials, our self-clinching fasteners provide strong retention and reliable load performance.
Complete Self-Clinching Fastener Range
Including self-clinching nuts, standoffs, studs, pins, and special fasteners to support diverse design and assembly requirements.
Own Factory, Direct Control
With in-house manufacturing, RivetFast maintains full control over production, quality, and lead times—supporting stable supply and flexible specifications.
Not sure which locating pin fits your application?
Contact RivetFast with your sheet metal thickness, component alignment needs, and quantity — we will respond within 24 hours.
Q1:What sheet thickness is suitable for locating pins?
Suitable sheet thickness depends on the pin diameter. Always refer to RivetFast specifications to ensure optimal clinching performance.
Q2:Are stainless steel locating pins available?
Yes, RivetFast offers stainless steel pins for corrosion-resistant applications.
Q3:Can locating pins be customized?
Yes, custom diameters, lengths, and material options are available.
Q4:How are locating pins installed?
Use a controlled press-fit process with parallel tooling surfaces to embed the pin securely.
Q5:Can locating pins resist vibration or push-out?
Yes, properly installed self-clinching locating pins provide reliable push-out resistance and maintain component alignment.
Q6:What is the typical lead time for bulk orders?
Lead time varies based on quantity and customization requirements. Contact RivetFast for detailed scheduling.
This product is part of RivetFast’s Self-Clinching Fasteners product range and is manufactured to meet industrial fastening requirements.
